| Technical details |
| Original model name |
iPhone 16 Pro Max |
| Launch date |
2024 |
| Processor |
| Processor model |
A18 Pro |
| Processor family |
Apple |
| Processor cores |
6 |
| Coprocessor |
 |
| Coprocessor cores |
16 |
| Coprocessor model |
Neural Engine |
| Efficient cores |
4 |
| Performance cores |
2 |
| Neural processor unit (NPU) |
Apple Neural Engine (ANE) |
| Display |
| Contrast ratio (typical) |
2000000:1 |
| Display diagonal |
17.5 cm (6.9") |
| Display brightness |
1000 cd/m |
| Display resolution |
2868 x 1320 pixels |
| Maximum refresh rate |
120 Hz |
| Pixel density |
460 ppi |
| Fingerprint resistant |
 |
| Panel type |
OLED |
| Screen shape |
Flat |
| Brand specific technologies |
Always-on display, Dynamic Island, Haptic touch, ProMotion, True Tone, Wide color (P3) |
| Display brightness (min) |
1 cd/m |
|
 |
| Display glass type |
Ceramic Shield |
| High Dynamic Range (HDR) supported |
 |
| Oleophobic coating |
 |
| High Dynamic Range (HDR) technology |
Dolby Vision, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG) |
| Maximum display brightness (HDR) |
1600 cd/m |
| Maximum display brightness (Outdoor) |
2000 cd/m |
| Display technology marketing name |
Super Retina XDR |
| Ports & interfaces |
| USB connector type |
USB Type-C |
| USB version |
3.2 Gen 2 (3.1 Gen 2) |
| USB port |
 |
| Weight & dimensions |
| Weight |
227 g |
| Height |
163 mm |
| Width |
77.6 mm |
| Depth |
8.25 mm |
| Energy management |
|
 |
| USB Type-C charging port |
 |
| USB Type-C required charging power (min) |
4.5 W |
| USB Type-C required charging power (max) |
30 W |
| Operational conditions |
| Operating altitude |
0 - 3000 m |
| Operating relative humidity (H-H) |
5 - 95% |
| Storage temperature (T-T) |
-20 - 45 C |
| Operating temperature (T-T) |
0 - 35 C |
| Endurance |
| Energy efficiency class |
B |
| International Protection (IP) code |
IP68 |
| Energy efficiency scale |
A to G |
| Battery endurance per cycle |
2880 min |
| Repeated free fall reliability class |
C |
| Battery endurance in cycles |
1000 |
| Repairability class |
C |
| Networking |
| Wi-Fi standards |
Wi-Fi 7 (802.11be) |
| Bluetooth version |
5.3 |
| Bluetooth |
 |
| Wi-Fi |
 |
| 2G bands (primary SIM) |
850,900,1800,1900 MHz |
| 3G bands supported |
850,900,1700,1900,2100 MHz |
| SIM card type |
NanoSIM + eSIM |
| AirPlay |
 |
| Near Field Communication (NFC) |
 |
| 4G standard |
LTE-TDD & LTE-FDD |
| 3G standards |
DC-HSDPA, HSPA+, UMTS |
| 2G standards |
Edge, GSM |
| SIM card capability |
Dual SIM |
| MIMO |
 |
| iBeacon |
 |
| Voice over LTE (VoLTE) supported |
 |
| Mobile network generation |
5G |
| 4G data rate (max) |
1000 Mbit/s |
| Frequency band |
Penta-band |
| 5G standard |
NR, NR mmWave, Sub6 |
| Storage |
| Compatible memory cards |
Not supported |
| Navigation |
| Electronic compass |
 |
| GPS (satellite) |
 |
| Wi-Fi positioning |
 |
| GLONASS |
 |
| Position location |
 |
| BeiDou |
 |
| Galileo |
 |
| Quasi-Zenith Satellite System (QZSS) |
 |
| NavIC |
 |
| Certificates |
| Head SAR (EU) |
1.22 W/kg |
| Body SAR (EU) |
1.45 W/kg |
| Head SAR (USA) |
1.01 W/kg |
| Body SAR (USA) |
1.15 W/kg |
| Operating system/software |
| Platform |
iOS |
| Operating system installed |
iOS 18 |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64 |
| Mac operating systems supported |
Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma |
| Virtual assistant |
Apple Siri |
| App distribution platform |
Apple App Store |
| Apple Intelligence |
 |
| Camera |
| Digital zoom |
25x |
| Image stabilizer |
 |
| Video capture resolution (max) |
3840 x 2160 pixels |
| Auto focus |
 |
| Night mode |
 |
| Resolution at capture speed |
1280x720@30fps, 1920x1080@120fps, 1920x1080@240fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@100fps, 3840x2160@120fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 3840x2160@60fps |
| Panorama |
 |
| Face detection |
 |
| Maximum frame rate |
240 fps |
| Continuous shooting mode |
 |
| Image stabilizer type |
Optical Image Stabilization (OIS) |
| Geotagging |
 |
| Video recording modes |
720p, 1080p, 2160p |
| Rear camera resolution (numeric) |
48 MP |
| Front camera resolution (numeric) |
12 MP |
| Red-eye correction |
Y |
| Portrait mode |
 |
| Rear camera type |
Triple camera |
| Second rear camera resolution (numeric) |
48 MP |
| Rear camera aperture number |
1.78 |
| Second rear camera aperture number |
2.2 |
| Front camera aperture number |
1.9 |
| Front camera type |
Single camera |
|
12 MP |
| Third rear camera aperture number |
2.8 |
| Front camera flash |
 |
| Rear camera flash |
 |
| Second rear camera field of view (FOV) angle |
120 |
| Third rear camera field of view (FOV) angle |
20 |
| Rear camera focal length |
2.4 cm |
| Second rear camera focal length |
1.3 cm |
| Third rear camera focal length |
12 cm |
| Third rear camera lens elements |
7-element lens |
| Optical zoom out |
2x |
| Optical zoom in |
5x |
| Lens cover material |
Sapphire crystal |
| Macro photography |
 |
| Camera image formats supported |
DNG, HEIF, JPEG |
| Audio zoom |
 |
| Camera video formats supported |
H.264, HEVC, ProRes |
| Camera High Dynamic Range (HDR) mode |
 |
| Photonic Engine |
 |
| Deep Fusion |
 |
| Portrait Lighting |
 |
| QuickTake video |
 |
| Stereo recording |
 |
| Slow motion mode |
 |
| Spatial photos |
 |
| Lens correction |
 |
| Wind noise reduction |
 |
| Camera button controls |
Cameras, Depth, Exposure, Styles, Tone, Zoom |
| Battery |
| Battery technology |
Lithium-Ion (Li-Ion) |
| Continuous audio playback time |
105 h |
| Continuous video playback time |
33 h |
| Continuous video playback time (streamed) |
29 h |
| Other features |
| Doesn't contain |
Arsenic, Mercury, PVC/BFR |
| Repairability index |
8.3 |
| Design |
| Form factor |
Bar |
| Waterproof up to |
6 m |
| Housing material |
Glass, Titanium |
| Protection features |
Dust resistant, Splash proof, Water resistant |
| Sensors |
| Barometer |
 |
| Proximity sensor |
 |
| Ambient light sensor |
 |
| Accelerometer |
 |
| Gyroscope |
 |
| LiDAR sensor |
 |
| Performance |
| Speakerphone |
 |
| Vibrating alert |
 |
| Fingerprint reader |
 |
| Fast charging |
 |
| Voice commands |
 |
| Video call |
 |
| Face recognition |
 |
| Hearing aid compatibility |
 |
| Wireless charging |
 |
|
6 |
| Accessibility features |
AssistiveTouch, Closed Captions, Magnifier, Real-time text (RTT), Spoken Content, Switch Control, Teletype (TTY), Type to Siri, Voice Control, VoiceOver, Zoom, Eye Tracking, Live Captions, Personal Voice, Live Speech, Vocal Shortcuts |
| Crash detection |
 |
| Emergency SOS (satellite) |
 |
| Spatial audio |
 |
| Action button |
 |
| Action button features |
Accessibility, Camera, Controls, Flashlight, Focus, Magnifier, Recognize Music, Shortcut, Silent mode, Translate, Voice Memo |
| Camera button |
 |
| Screen sharing |
 |
| Voice isolation |
 |
| Wide Spectrum |
 |
| Roadside assistance |
 |
| Features |
| Multimedia |
| Audio system |
Dolby Atmos |
| Audio formats supported |
AAC, ALAC, FLAC, MP3, APAC |
| Image formats supported |
GIF, JPG, TIFF |
| Video formats supported |
H.264, HEVC, ProRes, AV1 |
| Number of microphones |
4 |
| Document formats supported |
DOC, DOCX, HTM, HTML, ICS, Key, Numbers, PDF, PPT, PPTX, Pages, RTF, TXT, USDZ, VCF, XLS, XLSX |
| Archive formats supported |
Zip |
